TCS Indicator
- The TCS operated when the front brake pad temperature rises excessively.
- The TCS switch is OFF.
- One or more if these components are faulty: Heated oxygen sensor, Manifold absolute pressure sensor, Crankshaft position sensor, Engine coolant temperature sensor, Throttle position sensor, Top dead center sensor, Top dead sensor 2, Intake air temperature sensor, Exhaust gas recirculation, Barometric pressure sensor, Idle air control valve, VTEC pressure switch, Knock sensor, Fuel supply system, Automatic transaxle, Misfire detection system of the PGM-FI system.
