System Pressure

  1. Check and note existing pressure. Remove pressure regulating valve from fuel distributor. See Fig 1 .
  2. Adjust pressure by changing shims in shim stack. Add shims to raise system pressure. Remove shims to lower system pressure.
  3. A shim change of .020" (.5 mm) will change system pressure approximately 4.2 psi. (.3 kg/cm2 ). Ensure any replacement shims are identical in diameter to existing shims.
Fig 1: Adjusting System Pressure
G61271
