Control Solenoids

Disconnect electrical connector from each solenoid. See Figure 7. Using jumper wires, energize solenoid. Ensure each solenoid clicks. Measure resistance across solenoid terminals. Resistance should be 26-33 ohms at room temperature. If any solenoid does not test as described, replace solenoid.
