Removal And Installation: Notes

CAUTION: During maintenance, take care not to contact the parts or tools to the caliper because the paint of caliper will be scratched.
Fig 1: Removing/Installing Camshaft Position Sensor Removing Step
G02485789Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
