Cylinder - Key/Lock: Installation

Fig 1: Installing Key/Lock Cylinder

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

The ignition key (1) must be in the key cylinder (2) for cylinder installation.

1. Install the key cylinder into the housing using care to align the end of the key cylinder (2) with the ignition switch.
2. Push the key cylinder (2) in until it clicks.
3. Replace the upper and lower shrouds.
4. Reconnect the battery.
