Inflatable Restraint Diagnostic Energy Reserve Module (SDM)

Fig 1: Inflatable Restraint Diagnostic Energy Reserve Module (SDM) - 10-Pin Connector (Yellow)

G00181083

Courtesy of GENERAL MOTORS CORP.
