Automatic Transmission Shift Lock Control Component Views

Fig 1: Identifying Automatic Transmission Shift Lock Control Solenoid
GM750966Courtesy of GENERAL MOTORS CORP.
Callout Component Name
1 Lower Console
2 Automatic Transmission Shift Lock Actuator
