Indicator (Model With Boot Shifter)

  1. Remove the indicator.
    G13225499Courtesy of SUBARU OF AMERICA, INC.
  2. Remove the boot.
CAUTION: Be careful not to damage the boot claw.
G13225500Courtesy of SUBARU OF AMERICA, INC.
