Home >> Suzuki >> 2007 >> Reno Automatic >> Repair and Diagnosis >> Engine Performance >> Engine Control Systems >> Engine - Diagnostic Introduction >> Fuel Pump Relay Circuit Check >> Notes

Fuel Pump Relay Circuit Check: Notes

Fig 1: Engine Control Module - Circuit Diagram

G04817365

Courtesy of SUZUKI OF AMERICA CORP.
