Function Diagram

WARNING: This page is about a different car, the 2008 Acura TL and 2007 Acura TL. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Navigation System - Function Diagram
G05463114Courtesy of AMERICAN HONDA MOTOR CO., INC.
