Miscellaneous Components

MISCELLANEOUS COMPONENTS LOCATION

Component	Location
ABS Hydraulic Unit	Right of left front wheelwell. See Figure .
A/C Evaporator Temperature Regulator	On left side of A/C-heater unit.
A/C Diode	Inside A/C blower housing.
A/C Potentiometer	Under dash, left of glove box.
Airflow Meter	Behind air cleaner housing, on top of engine.
Alarm Horn	Below air cleaner intake, behind right side headlights.
Anti-Theft Horn	Under left side of fresh air intake cowl.
Auto Charging Flashlight	In glove box.
Auxiliary Fan Blocking Diode	Inside front harness, near right headlights.
Auxiliary Fan Normal Speed Resistor	On auxiliary fan shield, ahead of radiator.
Cruise Control Actuator	Below hydraulic fluid reservoir, behind left side headlights. See Figure .
Diagnostic Connector	On bracket next to main fuse/relay box. See Figure .
Filter Capacitor	Behind right side headlights.
Memory Seat Control Module	Under front of driver's seat.
Main Fuse/Relay Box	On left front wheelwell. See Figure .
Hazard/Turn Signal Flasher	Under left side of steering column.
Heater Regulator	Behind temperature select control knob.
Lock Heater	In left front door.
On-Board Computer Relay Box	Under left side of dash. See Figure .
On-Board Computer Horn Diode	Next to alarm horn.
On-Board Computer Horn	Under left side of fresh air intake cowl.
Power Window Circuit Breaker	Under left side of dash.
Seat Belt Warning Chime	Under dash, above and to left of glove box.
TDC Sensor Connector	Attached to thermostat housing. See Figure .
Windshield Washer Jet Heaters	On windshield washer jet nozzles.
