Comprehensive Exterior Lighting Systems
The following information outlines the function of the exterior lighting system and the adaptive headlights. The F01/F02 are equipped with standard adaptive headlights.
The F01/F02 features the welcome light, making the vehicle even more customer friendly. The exterior lighting system is switched on for approximately 20 seconds when the vehicle is unlocked. This has the advantage of locating the vehicle more easily under unfavorable light conditions.
A further feature is the daytime driving light that can be activated or deactivated via the Personal Profile.
Control units for the exterior lighting system F01/F02
COMPONENTS DESCRIPTION CHART
| Index | Explanation |
|---|---|
| 1 | Car Access System |
| 2 | Junction box electronics |
| 3 | Crash safety module |
| 4 | Steering column switch cluster |
| 5 | Rain/light/solar/condensation sensor |
| 6 | Roof functions center |
| 7 | Controller |
| 8 | Integrated chassis management |
| 9 | Trailer module |
| 10 | Footwell module |
| 11 | Central gateway module |
| 12 | Electronic transmission control |
