Home >> Cadillac >> 2003 >> Seville SLS >> Repair and Diagnosis >> Brakes >> Traction Control >> Antilock Brake System >> Repair Instructions >> Traction Control Switch Replacement >> Removal Procedure

Removal Procedure

  1. Turn OFF the ignition.
  2. Remove the console trim plate (1). Refer to INSTRUMENT PANEL, GAGES, AND CONSOLE  in Instrument Panel, Gages and Console.
  3. Remove the traction control switch mounting screws.
  4. Remove the traction control switch (2) from the trim plate.
    Fig 1: Removing Traction Control Switch From Trim Plate
    G02069270Courtesy of GENERAL MOTORS CORP.
