Removal Procedure

  1. Remove the rear upper compartment trim. Refer to Rear Compartment Trim Panel Replacement .
    2. Fig 1: View Of Rear Park Assist Module
    GM1466263Courtesy of GENERAL MOTORS CORP.
  2. Release the tabs securing the rear integration module (2) to the module bracket.
  3. Disconnect the electrical connectors.
