Liftgate Side Sensor Replacement

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure Liftgate Upper Side Trim Finish Panel Replacement
1	Rear End Spoiler Bolt CAUTION: Fastener Caution Tighten 5 N.m (44 lb in)
2	Liftgate Side Sensor Retainer [4x]
3	Liftgate Side Sensor Procedure Disconnect the electrical connector.
