Power Mirror Switch
Remove power mirror switch and disconnect harness connector. See POWER MIRROR SWITCH under REMOVAL & INSTALLATION. Check continuity between appropriate terminals at mirror switch (component side) with switch in specified position. See POWER MIRROR SWITCH CONTINUITY TEST table. See Figure . If continuity is not as specified, replace power mirror switch.
POWER MIRROR SWITCH CONTINUITY TEST
| Switch Position | Continuity Between Terminals No. | |
|---|---|---|
| Driver's Mirror | ||
| Up | 4 & 8; 6 & 10 | |
| Down | 4 & 6; 8 & 10 | |
| Left | 4 & 8; 7 & 10 | |
| Right | 4 & 7; 8 & 10 | |
| Passengers Mirror | ||
| Up | 1 & 10; 4 & 8 | |
| Down | 1 & 4; 8 & 10 | |
| Left | 2 & 10; 4 & 8 | |
| Right | 2 & 4; 8 & 10 | |
