Wheel Alignment Specifications

For wheel alignment specifications, see Fig 1 or Fig 2 .

Fig 1: Wheel Alignment Specifications (Without ACR Package)

Courtesy of CHRYSLER CORP.

Fig 2: Wheel Alignment Specifications (With ACR Package)

Courtesy of DAIMLERCHRYSLER CORPORATION
