Ignition System: Description

Fig 1: View Of Coil And Two Spark Plugs

Courtesy of DAIMLERCHRYSLER CORP.

The High Energy Ignition (HEI) system uses one coil and two spark plugs per cylinder. Individual coils for each cylinder ensure consistent performance at high RPM and allow individual cylinder spark control. Dual spark plugs provide more complete combustion, particularly near the cylinder walls, thus decreasing emissions. Also, HEI enhances combustion efficiency when firing mixtures diluted by EGR (Exhaust Gas Recirculation), which in turn improves overall efficiency and lowers emissions.
