CAPACITOR, Ignition: Installation: 3.5L

Fig 1: IGNITION CAPACITOR - 3.5L
GC0080071Courtesy of CHRYSLER LLC
  1. Install ignition coil capacitor (2) and bolt (1).
  2. Tighten bolt to 28 N.m (20.5 ft. lbs.).
  3. Connect electrical connector (3).
  4. Connect negative battery cable and tighten nut to 5 N.m (45 in. lbs.).
