Home >> Eagle >> 1990 >> Talon Base, Automatic >> Repair and Diagnosis >> Body & Frame >> Power Windows >> Component Tests >> Power Window Sub-Switch

Power Window Sub-Switch

Check for continuity in accordance to the following connection table. See Fig 1 .

Fig 1: Power Window Sub-Switch Continuity Table

G00156103

Courtesy of CHRYSLER CORP.
