Reverse Clutch: Notes

SPECIAL TOOL SPECIFICATION

G03915058
 Compressor, Clutch Spring 307-015 (T65L-77515-A)
MATERIAL SPECIFICATION

Item Specification
Automatic Transmission Fluid XT-5-QM MERCON® V
Fig 1: Exploded View Of Reverse Clutch
G03951499Courtesy of FORD MOTOR CO.
