Home >> Genesis >> 2017 >> G90 5.0 Ultimate, AWD >> Repair and Diagnosis >> Body & Frame >> Door Locks >> Power Trunk Module >> Power Trunk Inner Switch >> Repair Procedures >> Inspection

Repair Procedures: Inspection

  1. Remove the trunk inner switch.
  2. Check for continuity between terminals of the trunk inner switch.
Fig 1: Trunk Inner Switch Connector Terminals
G11419659Courtesy of HYUNDAI MOTOR AMERICA
Fig 2: Trunk Inner Switch Terminal Continuity Chart
G11419660Courtesy of HYUNDAI MOTOR AMERICA
