Home >> Genesis >> 2021 >> G90 3.3T Premium, AWD >> Repair and Diagnosis >> Engine Performance >> Engine Control Systems >> Engine Control System - 3.3L >> Manifold Absolute Pressure Sensor (MAPS) >> Specifications >> Specification

Manifold Absolute Pressure Sensor (MAPS): Specifications: Specification

Pressure (kPa) Output Voltage (V)
20.0 0.5
160 2.5
300 4.5
G14233097Courtesy of HYUNDAI MOTOR AMERICA
