Test Pattern

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2004 Honda Odyssey, 2003 Honda Odyssey, 2002 Honda Odyssey, 2001 Honda Odyssey, and 2000 Honda Odyssey. However, it is still accessible from the selected car via links, so may be relevant.

All 32 colors including black must be indicated (including the back ground color).

Fig 1: Test Pattern Screen
G01520481Courtesy of AMERICAN HONDA MOTOR CO., INC.
