Condenser Removal/Installation
WARNING: This page is about a different car, the 2004 Mazda 3. However, it is still accessible from the selected car via links, so may be relevant.
- Disconnect the negative battery cable.
- Remove the liftgate upper trim. (See LIFTGATE UPPER TRIM REMOVAL/INSTALLATION .)
- Remove in the order indicated in the table.REMOVAL ORDER OF CONDENSER
1 Bolt 2 Connector 3 Condenser - Install in the reverse order of removal.
