Ram (Rear Area Module)

  1. Disconnect the negative (-) battery terminal.
  2. Remove the left luggage side trim (Refer to INTERIOR TRIM ).
  3. Remove the RAM (A) after loosening the 7 connectors and the 3 RAM mounting bolts (A).
    Fig 1: Identifying Ram Mounting Bolts
    G05324917Courtesy of HYUNDAI MOTOR CO.
  4. Installation is the reverse of removal.
