Repair and Diagnosis: Electrical: Horns: Inspection: Notes

Test the horn by connecting battery voltage to the 1 terminal and ground the 2 terminal.

The horn should make a sound. If the horn fails to make a sound, replace it.

Fig 1: Testing Horn By Connecting Battery Voltage To 1 Terminal And Ground 2 Terminal

Courtesy of HYUNDAI MOTOR CO.
