Engine Electrical System - General Information: Specifications: Battery

CMF45L - DIN

BATTERY (CMF45L - DIN) SPECIFICATIONS

Item	Specification
Capacity [20HR/5HR] (AH)	45 / 36
Cold Cranking Amperage (A)	410 (SAE / EN)
Reserve Capacity (Min)	80

AGM60L - DIN

BATTERY (AGM60L - DIN) SPECIFICATIONS

Item	Specification
Capacity [20HR/5HR] (AH)	60 / 48
Cold Cranking Amperage (A)	640 (SAE / EN)
Reserve Capacity (Min)	100

NOTE:

• COLD CRANKING AMPERAGE is the amperage a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2V or greater at a specified temperature.
• RESERVE CAPACITY RATING is amount of time a battery can deliver 25A and maintain a minimum terminal voltage of 10.5V at 26.7°C(80.1°F).
