Home >> Infiniti >> 2004 >> FX45 >> Repair and Diagnosis (Single Page) >> Engine Performance >> Engine Control System >> Snow Mode Switch >> Component Inspection >> Snow Mode Switch

Snow Mode Switch

  1. Check snow mode switch continuity between terminals 1 and 3 under the following condition.
    Fig 1: Testing Snow Mode Switch
    G00345626Courtesy of NISSAN MOTOR CO., U.S.A.
  2. If NG, replace snow mode switch.
    Fig 2: Snow Mode Switch Specifications
    G00345627Courtesy of NISSAN MOTOR CO., U.S.A.
