Cross-Sectional View
>>
2WD Models
2WD Models
Fig 1: Cross-Sectional View Of A/T Shift Lock System (2WD Models)
Courtesy of NISSAN NORTH AMERICA, INC.
Courtesy of NISSAN NORTH AMERICA, INC.
