Temperature Sending Unit Check
- Remove sending unit. Sending unit is located on front corner of engine, below distributor assembly. Measure sending unit resistance in heated water.
- Connect one ohmmeter lead to sending unit terminal and other lead to sending unit body (ground). Resistance should decrease as water temperature increases. See COOLANT TEMPERATURE SENDING UNIT RESISTANCE . If resistance does not vary as specified, replace sending unit.
COOLANT TEMPERATURE SENDING UNIT RESISTANCE
| Coolant Temperature °F (°C) | Ohms |
|---|---|
| 122 (50) | 226.0 |
| 293 (115) | 26.4 |
