Ignition Switch Test

  1. Remove lower instrument panel cover and driver-side knee bolster. Disconnect 7-pin connector from underdash fuse/relay box. See Fig 1 .
  2. Using DVOM, check continuity between specified connector terminals, with ignition switch in appropriate position. If continuity is not as specified, replace ignition switch.
Fig 1: Testing Ignition Switch Continuity
G99D05155Courtesy of ISUZU MOTOR CO.
