EHCU Connector Pin-Out Checks: Notes

• Disconnect Electronic Hydraulic Control Module.
• Perform checks with high impedance digital multimeter J-39200 or equivalent.

Fig 1: EHCU Connector Pin-Out Chart

Courtesy of ISUZU MOTOR CO.
