Audio System: Inspection: Removal

  1. Disconnect the negative (-) battery terminal.
  2. Remove the driver airbag module (A).

    (Refer to the RESTRAINTS (EXCEPT TROUBLESHOOTING) ).

    Fig 1: Identifying Driver Airbag Module
    G05187682Courtesy of KIA MOTORS AMERICA, INC.
  3. Remove the audio remote control switch (A) after removing fixing screws (2EA).
    Fig 2: Identifying Audio Remote Control Switch And Fixing Screws (2EA)
    G05187683Courtesy of KIA MOTORS AMERICA, INC.
