Front Strut Assembly: Disposal

  1. Fully extend the piston rod.
  2. Drill a hole on the (A) section to discharge gas from the cylinder.
    Fig 1: Drilling Areas To Remove Gas From Strut
    G04805347Courtesy of KIA MOTORS AMERICA, INC.
    CAUTION: The gas coming out is harmless, but be careful of chips that may fly when drilling. Be sure to wear safety goggles or eye protection when performing this task.
