Repair Procedures: Disposal

  1. Fully extend the piston rod.
  2. Drill a hole on the (A) section to remove gas from the cylinder.
    Fig 1: Hole Drilling Section
    G09743485Courtesy of KIA MOTORS AMERICA, INC.
    CAUTION:
    • The gas coming out is harmless but be careful of chips that may fly when drilling.
