Engine Starting System - 2.0L: Troubleshooting
| Symptom | Suspect Area | Remedy |
|---|---|---|
| Engine will not crank | Battery charge low | Charge or replace battery |
| Battery cables loose, corroded or worn out | Repair or replace cables | |
| Transaxle range switch (Vehicle with automatic transaxle only) | Refer to "DTC P0705-12: TRANSMISSION RANGE SENSOR CIRCUIT MALFUNCTION (PRNDL INPUT) " | |
| Fuse blown | Replace fuse | |
| Starter motor faulty | Replace | |
| Ignition switch faulty | Replace | |
| Engine cranks slowly | Battery charge low | Charge or replace battery |
| Battery cables loose, corroded or worn out | Repair or replace cables | |
| Starter motor faulty | Replace | |
| Starter keeps running | Starter motor faulty | Replace |
| Ignition switch | Replace | |
| Starter spins but engine will not crank | Short in wiring | Repair or replace wiring |
| Pinion gear teeth broken or starter motor | Replace | |
| Ring gear teeth broken | Replace fly wheel or torque converter |
NOTE:
- The battery must be in good condition and fully charged for this troubleshooting.
