Lexus
>>
2007
>>
GS 430
>>
Repair and Diagnosis
>>
Engine Performance
>>
Engine Control System (3UZ-FE)
>>
Throttle Body
>>
Components
Throttle Body: Components
Fig 1: Knock Sensor Replacement Components With Torque Specifications (1 Of 3)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
