Skid Control Buzzer: Components

Fig 1: Identifying Skid Control Buzzer Replacement Components (1 Of 2) With Torque Specifications
G06187629Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Identifying Skid Control Buzzer Components (2 Of 2)
G04949790Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
