Component Testing: Notes

COOLING FAN MOTOR CURRENT SPECIFICATIONS

Engine Amp.
Protege & 323
Single Speed 5.6-7.6
2-Speed (1)
Low Speed Circuit 8.8-9.7
High Speed Circuit 13.3-14.6
(1) For low speed and high speed circuit ammeter connections, see Figure .
