General Specifications
Automatic Transmission General Specifications (1 Of 2)
| Application | Engine | Refill Approximate Liters | Refill Capacity 1 U.S. Quarts | Fluid Type |
|---|---|---|---|---|
| 5R44E (4x2) | 2.3L | 9.4 | 9.9 | MAZDA ATF MERCON V or equivalent |
| 5R44E (4x2) | 3.0L | 9.5 | 10.0 | MAZDA ATF MERCON V or equivalent |
| 5R44E (4x4) | 3.0L | 9.8 | 10.3 | MAZDA ATF MERCON V or equivalent |
Automatic Transmission General Specifications (2 Of 2)
| Application | Engine | Refill Approximate Liters | Refill Capacity 1 U.S. Quarts | Fluid Type |
|---|---|---|---|---|
| 5R55E (4x2) | 4.0L (SOHC) | 9.5 | 10.0 | MAZDA ATF MERCON V or equivalent |
| 5R55E (4x4) | 4.0L (SOHC) | 9.8 | 10.3 | MAZDA ATF MERCON V or equivalent |
Approximate dry capacity, includes cooler and lines. Fluid level indicator should be used to determine actual fluid requirements and fluid specification. Check the level at normal operating temperature. DO NOT OVERFILL if it is necessary to add or replace fluid.
