Brake Pipe Installation Note

  1. When installing the brake pipe, align the marks made before removal with the ABS/TCS HU/CM as shown in the figure.
    Fig 1: Aligning Marks Made Before Removal
    G00991486Courtesy of MAZDA MOTORS CORP.
