Ignition Switch Inspection

  1. Remove the column cover. (See COLUMN COVER REMOVAL/INSTALLATION .)
  2. Disconnect the ignition switch connector.
  3. Inspect for continuity between the ignition switch terminals using an ohmmeter.
    • If not as specified, replace the ignition switch.
    Fig 1: Ignition Switch Continuity Table
    G00997273Courtesy of MAZDA MOTORS CORP.
    Fig 2: Locating Ignition Switch Connector Terminals
    G00997274Courtesy of MAZDA MOTORS CORP.
