Spark Test

  1. Release the fuel line pressure. (See BEFORE REPAIR PROCEDURE .)
  2. Remove the fuel pump relay pump relay.
  3. Verify that each high-tension lead and the connector is connected properly.
  4. Inspect the ignition system using the following procedure:
    WARNING:
    • High voltage in the ignition system can cause strong electrical shock which can result in serious injury. Avoid direct contact to the vehicle body during the following spark test.
    Fig 1: Spark Test
    G01345615Courtesy of MAZDA MOTORS CORP.
  5. Install the fuel pump relay.
