Generator Removal/Installation: Notes

WARNING:

When the battery cables are connected, touching the vehicle body with generator terminal B will generate sparks. This can cause personal injury, fire, and damage to the electrical components. Always disconnect the battery before performing the following operation.

Disconnect the negative battery cable.
Remove the under cover.
Remove the air pipe No.5, No.6, and air hose No.8 (with TC). (See INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [BP WITH TC] .)
Remove the intake manifold bracket.
Remove in the order indicated in the table.

Fig 1: Removing Intake Manifold Bracket & Torque Specifications
Courtesy of MAZDA MOTORS CORP.
Install in the reverse order of removal.
Inspect the drive belt deflection/tension. (See DRIVE BELT INSPECTION .)
