Knock Sensor (KS) Removal/Installation

1. Remove the battery cover. (See BATTERY REMOVAL/INSTALLATION [13B-MSP] .)
2. Disconnect the negative battery cable.
3. Disconnect the KS connector.
4. Remove the KS.
5. Install in the reverse order of removal.

Fig 1: LS Connector Screws With Torque Specifications

Courtesy of MAZDA MOTORS CORP.
