Exhaust side

Fig 1: Engine Components With Torque Specification (Exhaust Side)
G13149100Courtesy of MAZDA MOTORS CORP.
COMPONENT DESCRIPTION

1 Oil cooler water pipe component (with oil cooler)
(See Oil Cooler Water Pipe Component Installation Note .)
2 Oil filter body
(See Oil Filter Body Installation Note .)
3 Exhaust manifold bracket (2WD)
(See Exhaust Manifold Bracket Installation Note .)
