Engine Running

  1. Connect STAR tester or volt/ohmmeter as described in EQUIPMENT HOOK-UP  . Start engine and run until operating temperature is reached.
  2. Activate self-test and wait 2 minutes. Deactivate and reactivate self-test. DO NOT  turn off engine. System is now in Engine Running "CONTINUOUS MONITOR" Mode.
  3. Tap, move and wiggle the suspect sensor and/or harness. If a fault is detected, a service code will be stored and indicated. Proceed to CONTINUOUS MEMORY/MONITOR SELF-TEST CHART to continue with diagnosis.
Fig 1: Continuous Memory/Monitor Self-Test Chart
G94535
