Power Windows: Adjustments: Weatherstrip

1. Loosen four weatherstrip retaining screws. See Fig 1 .
2. Position weatherstrip so metal frame is even with lower edge of convertible top side rail.
3. Tighten retaining screws to 23-28 INCH Lbs. (2.5-3.2 N. m).

Fig 1: Adjusting Door Glass Weatherstrip

Courtesy of FORD MOTOR CO.
