Home >> Mitsubishi >> 2004 >> Montero XLS >> Repair and Diagnosis >> Transmission >> Automatic Trans >> Overhaul >> Transfer Case Adapter >> Disassembly And Assembly >> Notes

Disassembly And Assembly: Notes

Fig 1: Identifying Transfer Case Adapter Components
G00905416Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tools:
